ELECTRONIC WARFARE COMMUNICATIONS TEST & MEASUREMENT RADAR SATCOM

Power Amplifier Solutions Recommended for

ELECTRONIC WARFARE

[ Force Protection and Threat Simulators - Manpack, Vehicle, Fixed Site, HF to X-band ]

Cutting edge, compact, ultra broadband, solid state power amplifiers from Empower are playing a major role in Electronic Warfare applications.

Empower’s remarkable hardware and software architecture is advanced beyond any other amplifier supplier and offers break through capabilities not seen before in EW systems. Among these capabilities are Multi-domain operations where a single unit is capable of operating in Multi-Domain scenarios as a jamming, communications and radar transmitter at optimal performance with any type of modulation.

Features and Benefits

SKU 2210

2210: High Power RF Amplifier

150 - 450 MHz, 12000 Watt

Ruggedized Broadband Solid State Jamming and Communications Amplifier

At A Glance

PA Solutions for
Electronic Attack


Rev. 3.0
10-27-2021

EW High Power RF Amplifier Modules SKU 1097

Empower has delivered over 30,000 RCIED jammers at production rates exceeding 1000 amplifiers per month. Empower Systems are deployed on surface, airborne & ground tactical EW platforms.

Ruggedness

Higher breakdown voltages with GaN devices allow the amplifier to withstand high peak voltage waveforms and modulations such as Gaussian noise.

Reliable operation when subjected to high voltage standing wave ratio (VSWR) from the antenna which is a likely occurrence on a vehicle during combat.

GaN devices also come in smaller packages with higher power densities which enable the amplifiers to achieve smaller footprints of overall size and weight

All hardware is subject to over-temperature, EMI and EMC, shock and vibration and all other environmental testing required.

RF Jammer Military Amplifier System Shake Test
WATCH VIDEO

Amplifier System is transmitting at full power (1 KW CW) while being subjected to extreme, mil-standard testing for shock and vibration.


Modules 28VDC

PictureSKUData
Sheet
Start
(MHz)
Stop
(MHz)
Pout
(Watt)
Gain
(dB)
Modulation
Type
Size
(Inch)
Quote
1163 20 520 125 54 CW/FM/AM 7.0 x4.0 x1.2
1208 500 2700 100 50 CW/FM/AM 8.2x3.6x1.06
1164 800 3000 50 50 CW/FM/AM 6.4x3.4x1.0
1212 2000 6000 50 61 CW/FM/AM 7.0 x 4.0 x 1.1
1191 2500 6000 100 60 CW/FM/AM 8.0x6.5x1.0
Denotes best choices in this performance range.


Modules 48VDC

PictureSKUData
Sheet
Start
(MHz)
Stop
(MHz)
Pout
(Watt)
Gain
(dB)
Modulation
Type
Size
(Inch)
Quote
1213 1 30 50 53 CW/FM/AM 7.0 x 4.0 x 1.12
1193 20 1000 100 53 CW/FM/AM 7.0x4.0x1.2
1211 500 2500 100 57 CW/FM/AM/Pulse 7.0 x 4.0 x 1.1
1199 1000 3000 100 61 CW/FM/AM 7.0x4.0x1.1
1219 500 6000 25 62 CW/FM/AM/Pulse 7.0x4.0x1.1
1197 2000 6000 50 61 CW/FM/AM 7.0 x 4.0 x 1.1
Denotes best choices in this performance range.


Air Cooled Systems

PictureSKUData
Sheet
Start
(MHz)
Stop
(MHz)
Pout
(Watt)
Gain
(dB)
Modulation
Type
Size
(Inch)
Quote
2203 1 30 1000 60 CW/FM/AM R5U
2210 150 450 12000 73 Pulse R19U
2162 20 1000 1000 63 CW/FM/AM R5U
2199 500 2500 200 60 CW/FM/AM/Pulse R5U
2202 500 2500 1000 63 CW/FM/AM/Pulse R8U
2180 1000 2500 2000 64 CW/FM/AM R5U+R3U
2170 1000 3000 1000 63 CW/FM/AM R5U
2211 2700 3200 1200 62 Pulse R3U
2239 2900 3500 1000 65 Pulse, CW R3U
2214 2900 3500 8000 70 Pulse R19U
2240 5200 5900 1000 65 Pulse, CW R3U
2217 5200 5900 8000 70 Pulse R18U
2223 500 6000 150 53 CW/FM/AM/Pulse R5U
2215 1900 6000 200 53 CW/FM/AM/Pulse R5U
2221 9000 10000 8000 70 Pulse R18U
Denotes best choices in this performance range.


Liquid Cooled Systems

PictureSKUData
Sheet
Start
(MHz)
Stop
(MHz)
Pout
(Watt)
Gain
(dB)
Modulation
Type
Size
(Inch)
Quote
2237 1000 2000 40000 81 Pulse 40U
2236 2800 3500 24000 74 CW, AM, FM, Pulse 80 U
2238 2000 4000 12000 76 Pulse, CW 40U
2225 5200 5900 90000 80 Pulse R38U
Denotes best choices in this performance range.
